An air duct heater consists of an aligned array of electrical heating elements in which the longitudinal and transverse pitches

Answer:

The change in entropy of the steam is 2.673 kJ/K

Explanation:

The mass of the liquid-vapor mixture is 1.5 kg

The mass in the liquid phase is calculated as 3/4 × 1.5 kg = 1.125 kg

The mass in the vapor phase is calculated as 1.5 - 1.125 = 0.375 kg

According to the steam tables

At a pressure of 200 kPa (200/100 = 2 bar), the specific entropy of steam is found to be 7.127 kJ/kgK

The entropy of steam can be calculated as specific entropy multiplied by mass = 7.127 × 0.375 = 2.673 kJ/K

An item of protective gear that shields individuals passing by from stray sparks or metal during the welding process performed by another worker is known as: E. Welding Screens.

An operator is a person tasked with joining two or more metals using a technique called wielding.

In the course of wielding, both sparks and tiny metallic fragments are released, which pose a danger to the operator and others working nearby.

As a result, the equipment outlined below should be worn or utilized directly by a worker actuating the wielding process:

• Visors.

• Goggles.

• Protective clothing.

• Dark walls.

Nonetheless, a type of protective gear that defends other workers nearby from stray sparks or metallic fragments while the operator (worker) is in the act of welding is called welding screens.

Find more information:

Answer:

The velocity at exit U_2 is 578.359 m/s

The exit diameter d_e is 1.4924 cm

Explanation:

Provided data includes:

Length of the nozzle L = 25 cm

Inlet diameter d_i = 5 cm

At the nozzle entrance (state 1): Temperature T_1 = 325 °C, Pressure P_1 = 700 kPa, Velocity U_1 = 30 m/s, Enthalpy H_1 = 3112.5 kJ/kg, Volume V_1 = 388.61 cm³/gAt the nozzle exit (state 2): Temperature T_2 = 250 °C, Pressure P_2 = 350 kPa, Velocity U_2, Enthalpy H_2 = 2945.7 kJ/kg, Volume V_2 = 667.75 cm³/g To determine:a. Exit Velocity U_2b. Exit Diameter d_e

a.The Energy Equation can be represented by:ΔH + ΔU² / 2 + gΔz = Q + WAssuming Q = W = Δz = 0Substituting the values yields:

(H_2 - H_1) + (U²_2 - U²_1)  / 2 = 0From which we can derive U_2 = sqrt((2* (H_1 - H_2 )) + U²_1) with the calculations leading to U_2 = sqrt ( 2 * 10^3 * (3112.5 -2945.7) + 900) yielding U_2 = 578.359 m/s

b.

Using mass balance approach, we have U_1 * A_1 / V_1 = U_2 * A_2 / V_2

This leads to U_1 * d_i² / V_1 = U_2 * d_e² / V_2, thus d_e = d_i * sqrt((U_1 / U_2) * (V_2 / V_1)). Hence, d_e = 5 * sqrt((30 / 578.359) * (667.75 / 388.61)) computes to d_e = 1.4924 cm

Response:

The cutting speed is calculated at 365.71 m/min

Clarification:

Given parameters include

diameter D = 250 mm

length L = 625 mm

Feed f = 0.30 mm/rev

cut depth = 2.5 mm

n = 0.25

C = 700

To find

the cutting speed that ensures the tool life coincides with the cutting time for the three parts

The formula for cutting time is given as

Tc =

where D refers to diameter, L refers to length and f refers to feed while V represents speed

Tc =

Tc =

Given the tool life is expressed as

T = 3 × Tc............................2

where T denotes tool life and Tc is the cutting duration

Calculating tool life by substituting values into equation 2 yields

T = 3 ×

This yields V = 365.71

Thus, the cutting speed calculates to 365.71 m/min
