Answer:
Devices & Their Corresponding Symbols
Device
Name
Device
Symbol
Device
Commentary
Notation
plan note symbol
One of the most crucial symbols found on architectural plans. This symbol indicates that there is a "note" relevant to the device or area
Switch
switch electrical symbol
light switch
Details such as style, possible model numbers, and colors of the switches will be noted in the plans.
Switch - 3 Way
3-way switch electrical symbol
Switch - 4 Way
4-way switch electrical symbol
Switch - Dimmer
dimmer switch electrical symbol
light switch dimmer
Information on the style, model numbers, and colors of the dimmers will be included in the notes.
Switch - Dimmer - 3 Way
3-way dimmer switch electrical symbol
Receptacle - Duplex
duplex receptacle electrical symbol
duplex receptacle
The style, model numbers, and colors of the receptacles will also be included in the notes.
Receptacle - Duplex - One Switched
duplex switched receptacle electrical symbol
Receptacle - Duplex - GFCI
duplex receptacle GFCI electrical symbol
duplex GFCI receptacle
The receptacles’ styles, model numbers, and colors will be detailed in the plans.
Receptacle - Duplex - Waterproof
duplex waterproof receptacle electrical symbol
when in use, weatherproof receptacle cover
The receptacle itself isn’t waterproof; it’s the cover that safeguards against environmental factors.
Receptacle - Single
single receptacle electrical symbol
clock receptacle
This receptacle is specifically designed for clocks, featuring a recessed socket to allow the clock to sit flush against the wall. Plans might include a "C" on the bottom right of the symbol to indicate it is tailored for a clock.
Receptacle - 240 VAC
240 VAC receptacle electrical symbol
240 VAC range receptacle
There may be a letter in the lower right corner denoting the receptacle’s purpose, such as "D" for dryer or "R" for range.
Receptacle - Quad
quad receptacle electrical symbol
quad receptacle
A quad receptacle consists of two duplex receptacles positioned in a double electrical box.
