Cold feedwater enters a 200-kPa open feedwater heater of a regenerative Rankine cycle at 70°C with a flow rate of 20 kg/s. Bleed

steam is available from the turbine at 200 kPa and 160°C. At what rate must the bleed steam be supplied to the open feedwater heater so that the feedwater leaves this unit as a saturated liquid?
The mass flow rate of bleed steam to be supplied to the open feedwater heater so that the feedwater leaves this unit as a saturated liquid is ___________ kg/s.

You might be interested in

The rate of flow of water in a pump installation is 60.6 kg/s. The intake static gage is 1.22 m below the pump centreline and re

mote1985 [299]

Answer:

The power of the pump is 23.09 kW.

Explanation:

Parameters

gravitational constant, $g = 9.81 m/s^2$

mass flow rate, $\dot{m} = 60.6 kg/s$

flow density, $\rho = 1000 kg/m^3$

efficiency of the pump, $\eta = 0.74$

output gauge pressure, $p_o = 344.75 kPa$

input gauge pressure, $p_i = 68.95 kPa$

cross-sectional area of output pipe, $A_o = 0.069 m^2$

cross-sectional area of input pipe, $A_i = 0.093 m^2$

height of discharge, $z_o = 1.22 m - 0.61 m = 0.61 m$ (evaluated at pump’s maximum height of 1.22 m)

input height, $z_i = 0 m$

hydraulic power of the pump, $P =? kW$

Initially, the volumetric flow (Q) needs to be determined

$Q = \frac{\dot{m}}{\rho}$

$Q = \frac{60.6 kg/s}{1000 kg/m^3}$

$Q = 0.0606 m^3/s$

Next, compute the velocity (v) for both input and output

$v_o = \frac{Q}{A_o}$

$v_o = \frac{0.0606 m^3/s}{0.069 m^2}$

$v_o = 0.88 m/s$

$v_i = \frac{Q}{A_i}$

$v_i = \frac{0.0606 m^3/s}{0.093 m^2}$

$v_i = 0.65 m/s$

Subsequently, the total head (H) can be calculated

$H = (z_o - z_i) + \frac{v_o^2 - v_i^2}{2 \, g} + \frac{p_o - p_i}{\rho \, g}$

$H = (0.61 m - 0 m) + \frac{{0.88 m/s}^2 - {0.65 m/s}^2}{2 \, 9.81 m/s^2} + \frac{(344.75 Pa-68.95 Pa)\times 10^3}{1000 kg/m^3 \, 9.81 m/s^2}$

$H = 28.74m$

Finally, the computation of pump power is done as follows

$P = \frac{Q \, \rho \, g \, H}{\eta}$

$P = \frac{0.0606 m^3/s \, 1000 kg/m^3 \, 9.81 m/s^2 \, 28.74m}{0.74}$

$P = 23.09 kW$
