A student pulls a block over a rough surface with a constant force FP that is at an angle θ above the horizontal, as shown above

Response:

Clarification:

Refer to the diagram indicating the charges on the specified sphere (see attachment).

The electric field at the stated positions is

E(r) = 0 for r≤a.  Equation 1

E(r) = kq/r² for a<r<b.   Equation 2

E(r) = 0 for b<r<c.      Equation 3

E(r) = kq/r² for r>c.    Equation 4.

We understand that electric potential correlates with the electric field through

V = Ed

A. To compute the potential at the outer surface of the hollow sphere (r=c), we determine that the electric field there is

E = kQ / r²

Then,

V = Ed,

At d = r = c

Thus,

Vc = (kQ / c²) × c

Vc = kQ / c

As a result, the total charge Q consists of +q, -q, and +q

Hence, Q = q - q + q = q

V = kq / c

B. To calculate the potential at the inner surface of the hollow sphere (r=b), we have

V = kQ/r

V = kQ / b,   noting that r = b

So, Q = q

V = kq / b

C. At r = a

Following from equation 1:

E(r) = 0 for r≤a.  Equation 1

The electric field at the surface of the solid sphere is 0, E = 0N/C

Thus,

V = Ed = 0 V

Consequently, the electric potential at the solid sphere's surface is 0.

D. At r = 0

The electric potential can be determined by

V = kq / r

As r approaches 0,

V = kq / 0

V approaches infinity.

Answer:

Explanation:

Consider the following:

Length= 2L

Linear charge density=λ

Distance= d

K=1/(4πε)

The electric field measured at point P

Thus,

Now, by applying integration to the equation above

The solution leads to the conclusion that m1 = m2

For mass m1, the force balance in the y direction equals zero:
0 = T - m1*g
Rearranging gives:
m1*g = T

For mass m2, the force balance in the y direction equals zero:
0 = T - m2*g
Rearranging provides:
m2*g = T

Setting these two equal allows us to solve for m1:
m1*g = m2*g

= m1 = m2

Explanation:

The force acting on each individual mass pulls down while the tension created by the other mass exerts an upward force due to the operation of the pulley system, resulting in balanced forces on both masses.
