(a) Calculate the absolute pressure at the bottom of a fresh- water lake at a depth of 27.5 m. Assume the density of the water i

<span>A force of 110 N is applied at an angle of 30</span>°<span> to the horizontal. Because the force does not align directly either vertically or horizontally with the sled, it can be broken down into two components based on sine and cosine.

For the component parallel to the ground:
x = rcos</span>β
<span>x = 110cos30</span>°
<span>x = 95.26

For the component perpendicular to the ground:
y = rsin</span>β
<span>y = 110sin30</span>°
<span>y = 55</span>

Answer:

Explanation:

The beacon is rotating at an angular speed of

so we have

We know that

At this point we have

So we can conclude with

Answer:

D, C, B, A

Explanation:

The derivative from a velocity-time graph provides the acceleration value.

Segment A

Segment B

Segment C

Segment D

Sorted from the lowest to the highest acceleration:

D, C, B, A

Answer:

a, 71.8° C, 51° C

b, 191.8° C

Explanation:

Given the data:

D(i) = 200 mm

D(o) = 400 mm

q' = 24000 W/m³

k(r) = 0.5 W/m.K

k(s) = 4 W/m.K

k(h) = 25 W/m².K

The heat generation formula can be articulated as follows:

q = πr²Lq'

q = π. 0.1². L. 24000

q = 754L W/m

Thermal conduction resistance, R(cond) = 0.0276/L

Thermal conduction resistance, R(conv) = 0.0318/L

Applying the energy balance equation,

Energy In = Energy Out

This equates to q, which is 754L

From the initial analysis, the temperature at the interface between the rod and sleeve is found to be 71.8° C

Additionally, the outer surface temperature records as 51° C

Furthermore, based on the second analysis, the calculated temperature at the center of the rod is determined to be 191.8° C

Power is defined as the speed at which work is performed on an object. Like all rates, power is measured in relation to time. It reflects how quickly a task is completed. Two identical tasks can be executed at varying speeds - one slower and the other faster. The equation P = Fv can be used, where P symbolizes power, F denotes force, and V represents average velocity. Calculating the average velocity gives us V = P/F, or V = (5.8 x 10^4 W) / (2.1 x 10^4 N), resulting in V = 2.8 m/s.
