For some metal alloy, a true stress of 345 MPa (50040 psi) produces a plastic true strain of 0.02. How much will a specimen of t
his material elongate when a true stress of 414 MPa (60050 psi) is applied if the original length is 520 mm (20.47 in.)? Assume a value of 0.22 for the strain-hardening exponent, n.
1 answer:
Answer:
24.348 mm
Explanation:
NB: I'll be uploading images to represent missing mathematical expressions or unique characters that aren’t easily typed
K = d / €^n
Note: d refers to the Greek letter epsilon.
K = 345 / 0.02⁰.²² = 816 mPa
The true strain based on the stress of 414 mPa =
€= (€/k)^1/n = (414/816)¹/⁰.²² = 0.04576
The actual relationship between true strain and length is given by
€ = ln(Li/Lo)
To isolate Li by rearranging,
Li = Lo.e^€
Li = 520e⁰.⁰⁴⁵⁷⁶
Li = 544.348 mm
The elongation can be calculated from
Change in L = Li - Lo = 544.348 - 520 change in L = 24.348 mm.
