Assume that the cart is free to roll without friction and that the coefficient of static friction between the block and the cart

is μs. Derive an expression for the minimum horizontal force that must be applied to the block in order to keep it from falling to the ground. Express your answer in terms of acceleration of gravity g and some or all of the variables m, M, and μs.

2 answers:

Keith_Richards [3.2K]1 month ago

6 0

Answer: $F=\frac{(M+m)g}{\mu _s}$

Explanation:

Provided:

The trolley, with mass M, is allowed to roll freely without friction.

The coefficient of friction between the trolley and mass m is $\mu _s$ .

A force F is applied to mass m.

The acceleration of the system is

$a=\frac{F}{M+m}$

The frictional force will counterbalance the weight of the block.

The frictional force is $=\mu _sN$

$N=ma$

$\mu _sN=mg$

$\mu _sma=mg$

$\mu _s=\frac{g}{a}$

$F=\frac{(M+m)g}{\mu _s}$

Maru [3.3K]1 month ago

3 0

Answer: N = fa/g

Explanation:

For the block not to fall, the frictional force, f, must equal the weight of the block:

f = mg. However, the block's horizontal motion is described by N = ma

Consequently,

f / N = g/ a .

Thus, a = g/f / N

As the maximum value of f / N is μs, we can infer that a ≥ g/μs, so that the block does not fall. Q.E.D.

N = fa/g

You might be interested in

A dog of mass 10 kg sits on a skateboard of mass 2 kg that is initially traveling south at 2 m/s. The dog jumps off with a veloc

inna [3103]

Answer:

17 m/s south

Explanation:

$m_1$ Mass of the dog = 10 kg

$m_2$ Mass of skateboard = 2 kg

v = Combined velocity = 2 m/s

$u_1$ Velocity of the dog = 1 m/s

$u_2$ Velocity of skateboard

In this scenario, linear momentum is conserved

$(m_1+m_2)v+m_1u_1+m_2u_2=0\\\Rightarrow u_2=-\dfrac{(m_1+m_2)v+m_1u_1}{m_2}\\\Rightarrow u_2=-\dfrac{(10+2)2+10\times 1}{2}\\\Rightarrow u_2=-17\ m/s$

The speed of the skateboard post-dog jump will be 17 m/s south, considering north as the positive direction

3 0

15 days ago

An object with charge q=−6.00×10−9C is placed in a region of uniform electric field and is released from rest at point A. After

kicyunya [3294]

Answer:

it’s a

Explanation:

utilized Google

8 0

1 month ago

A rod 12.0 cm long is uniformly charged and has a total charge of -20.0 µc. determine the magnitude and direction of the electri

Ostrovityanka [3204]

<span>Let Q be the charge, thus Q = -20.0 µC.</span>
Define D as the distance between the center of the rod and the specified point. Therefore,
D=0.32 - 0.12 = 0.2 m
<span>L = 0.12 m, which represents the length of the rod
</span><span>To find the magnitude and direction of the electric field along the axis of the rod at a point 32.0 cm from its center, use the formula:
</span><span>E = K·Q/r²
</span>or<span>E = kQ/D(D+L), where k</span> is a constant equal to 8.99 x 10<span>9</span> N m
2/C2.<span>Consequently,[TAG_21]]E=(</span>8.99 x 109 N m2/C2.* (-20.0 µC))/(<span>0.2 m*0.32m)</span><span>

</span>

7 0

1 month ago

Read 2 more answers

1)After catching the ball, Sarah throws it back to Julie. However, Sarah throws it too hard so it is over Julie's head when it r

Softa [3030]

Answer:

1)

$v_{oy}=11.29\ m/s$

2)

$y=7.39\ m$

Explanation:

Projectile Motion

When an object is projected near the surface of the Earth at an angle $\theta$ to the horizontal, it follows a trajectory known as a parabola. The only force acting on it (ignoring wind resistance) is gravity, affecting the vertical axis.

The height of a projectile can be calculated using

$\displaystyle y=y_o+V_{oy}t-\frac{gt^2}{2}$

where $y_o$ represents the initial height from ground level, $v_{oy}$ is the vertical component of the initial velocity, and t is the elapsed time.

The vertical speed component is expressed as

$v_y=v_{oy}-gt$

1) To proceed, we will determine the initial vertical velocity component since we lack sufficient data to calculate the absolute value of $v_o$ .

The peak height is attained when $v_y=0$ , which allows us to compute the time to reach that height.

$v_{oy}-gt_m=0$

Solving for $t_m$

$\displaystyle t_m=\frac{v_{oy}}{g}$

Thus, the maximum height reached is

$\displaystyle y_m=y_o+\frac{v_{oy}^2}{2g}$

We know this value is equal to 8 meters

$\displaystyle y_o+\frac{v_{oy}^2}{2g}=8$

Continuing with the calculations for $v_{oy}$

$\displaystyle v_{oy}=\sqrt{2g(8-y_o)}$

Substituting known values yields

$\displaystyle v_{oy}=\sqrt{2(9.8)(8-1.5)}$

$\displaystyle v_{oy}=11.29\ m/s$

2) At t=1.505 seconds, the ball is positioned above Julie’s head; we can calculate

$\displaystyle y=y_o+V_{oy}t-\frac{gt^2}{2}$

$\displaystyle y=1.5+(11.29)(1.505)-\frac{9.8(1.505)^2}{2}$

$\displaystyle y=1.5\ m+16,991\ m-11.098\ m$

$y=7.39\ m$

5 0

2 months ago

Derive an equation for the acceleration of block 3 for any arbitrary values of m3 and m2. Express your answer in terms of m3, m2

Ostrovityanka [3204]

The complete question is;

Block 1 sits on the floor with block 2 resting atop it. Block 3, which is stationary on a frictionless table, is attached to block 2 via a string that passes over a pulley depicted in the illustration below. Both the string and pulley have negligible mass.

Once block 1 is taken away without impacting block 2.

Derive an equation for the acceleration of block 3 considering arbitrary values for m3 and m2. Express your answer in terms of m3, m2, and relevant physical constants as needed.

Answer:

a = (m2)g/(m3 + m2)

Explanation:

Examining the attached illustration, by analyzing the free body diagram for block 3 and utilizing Newton's first law of motion, we reach the following formula;

T = (m3)a - - - (eq 1)

where;

T is the tension in the string

a is acceleration

m3 is the mass of block 3

Simultaneously, doing the same for Block 2, the free body diagram yields the equation; (m2)g - T = (m2)a

Rearranging for T results in;

T = (m2)g - (m2)a - - - (eq 2)

where;

g represents acceleration due to gravity

T is the tension in the string

a is acceleration

m2 is the mass of block 2

To deduce the acceleration, we will substitute (m3)a in place of T in eq 2.

Thus;

(m3)a = (m2)g - (m2)a

(m3)a + (m2)a = (m2)g

a(m3 + m2) = (m2)g

a = (m2)g/(m3 + m2)

3 0
