An electron moves in a region where the magnetic field is uniform and has a magnitude of 80 μT. The electron follows a helical p

ath which has a pitch of 9.0 mm and a radius of 2.0 mm. What is the speed of this electron as it moves in this region?

1 answer:

Softa [3K]2 months ago

6 0

Answer:

3.4 x 10⁴ m/s

Explanation:

Analyze the circular path of the electron

B = magnetic field = 80 x 10⁻⁶ T

m = mass of an electron = 9.1 x 10⁻³¹ kg

v = speed in the radial direction

r = radius of the circular trajectory = 2 mm = 0.002 m

q = charge of an electron = 1.6 x 10⁻¹⁹ C

For the electron’s circular movement

qBr = mv

(1.6 x 10⁻¹⁹) (80 x 10⁻⁶) (0.002) = (9.1 x 10⁻³¹) v

v = 2.8 x 10⁴ m/s

Now, consider the electron's movement in a straight line:

v' = speed in linear motion

x = distance traveled horizontally = 9 mm = 0.009 m

t = duration = $\frac{2\pi m}{qB}$ = $\frac{2\pi (9.1\times 10^{-31})}{(1.6\times 10^{^{-19}})(80\times 10^{-6})}$ = 4.5 x 10⁻⁷ sec

Using the formula

x = v' t

0.009 = v' (4.5 x 10⁻⁷)

v' = 20000 m/s

v' = 2 x 10⁴ m/s

The resultant speed is given by

V = sqrt(v² + v'²)

V = sqrt((2.8 x 10⁴)² + (2 x 10⁴)²)

v = 3.4 x 10⁴ m/s

You might be interested in

A new roller coaster contains a loop-the-loop in which the car and rider are completely upside down. If the radius of the loop i

Sav [3153]

Respuesta:

11.4 m/s

Explicación:

La fórmula para la aceleración centrípeta es:

$a=\frac{v^2}{R}$

donde, a es la aceleración, v la velocidad alrededor de la circunferencia y R el radio del círculo.

En este problema,

a = g = aceleración debida a la gravedad en la cima = $9.81\ m/s^2$

v = ?

R = 13.2 m

Por lo tanto,

$9.81=\frac{v^2}{13.2}$

$v^2=9.81\times {13.2}$

v = 11.4 m/s

8 0

2 months ago

A moving sidewalk 95 m in length carries passengers at a speed of 0.53 m/s. One passenger has a normal walking speed of 1.24 m/s

Maru [3345]

Answer: a) t = 1.8 x 10^2 seconds; b) t = 54 seconds; c) t = 49 seconds. Explanation: a) To determine the time of a stationary passenger on the sidewalk, we use the position formula. Given the constant speed of the walkway, we can calculate the time taken for set distances accordingly. This calculation extends into cases where combined velocities for walking are involved in subsequent queries.

3 0

1 month ago

Water is made of two hydrogen atoms and one oxygen atom bonded together. Julia is describing how water undergoes a physical chan

kicyunya [3294]

Steam transforms into gas as it escapes into the atmosphere. Even if you manage to capture the steam as it ascends, it can revert to H2O when it cools down. Due to the evaporation process, the final volume of water will differ from the original amount.

8 0

2 months ago

Read 2 more answers

Two trains are headed towards each other on the same track unbeknownst to the engineers. One departs San Francisco. Its average

ValentinkaMS [3465]

Answer:

7.166 hours = 430 minutes.

Explanation:

As both trains are approaching each other on the same track, their relative speed is the sum of their individual speeds. Hence, the time until they intersect (and inevitably collide) is determined by how long it takes for speeds of 65 mph and 55 mph to cover the total distance of 860 miles. One train will cover part of the distance, while the other will cover the remainder. To calculate the required time, we can apply the formula:

1 hour ---> 120 miles

X ----> 860 miles; hence X = (860 miles * 1 hour)/120 miles = 43/6 hours = 7.16666 hours. To convert this into minutes, recall that 1 hour equals 60 minutes; therefore, 43/6 hours * 60 minutes/hour = 430 minutes.

7 0

2 months ago

A spin bike has a flywheel in two parts—a 12.5 kg disk with radius 0.23 m, and a 7.0 kg ring with mass concentrated at the outer

Keith_Richards [3271]

Response:

Clarification:

Provided

weight of disk $m=12.5 kg$

diameter of disc $R=0.23 m$

weight of ring $m_r=7 kg$

Force $F=9.7 N$

$N=180 rpm$

$\omega =\frac{2\pi N}{60}$

$\omega =6\pi rad/s$

Overall moment of inertia

=Disc's moment of inertia +Ring's Moment of Inertia

$=0.5\cdot 12.5\times 0.23^2+7\times 0.23^2$

$=13.25\times 0.23^2=0.7009 kg-m^2$

At this point, Torque is $T=F\times R=I\cdot \alpha$

$9.7\times 0.23=0.7\times \alpha$

$\alpha =3.18 rad/s^2$

Utilizing $\omega _f=\omega +\alpha t$

$\omega _f=0$ in this scenario

$0=6\pi -3.18\times t$

$t=\frac{6\pi }{3.18}$

$t=5.92 s$

7 0
